Walraven Hexagon Head Bolt DIN933 BUP M8x80mm

61480880

Get project support

Walraven Hexagon Head Bolt DIN933 BUP M8x80mm

61480880

Consent

Features

  • according to DIN 933
  • material: steel, strength class 8.8
  • product is part of the Walraven UltraProtect® 1000 system
  • suitable for in- and outdoor applications
  • stands min. 1,000 hours salt spray test (max. 5% red rust) according to ISO 9227

Specifications

Walraven Hexagon Head Bolt (BUP1000)

Identification

Identification
Product Number 61480880

Product Dimensions

Product Dimensions
Thread Size Ref. letter: TS M8
Screw Length (mm) Ref. letter: ls 80
Thread Length (mm) Ref. letter: TL 76.25
Nominal Head Height (mm) Ref. letter: HH,n 5.3
Head Width (mm) Ref. letter: HW 13
Total Height (mm) Ref. letter: H 13
Total Width (mm) Ref. letter: W 15
Total Length (mm) Ref. letter: L 85
Screw Size Ref. letter: ds M8
Thread Pitch (mm) Ref. letter: TP 1.25

Technical characteristics

Technical characteristics
Head Shape Hexagon Head
Key Driver Size Ref. letter: Drive WAF13
Colour Zinc
Layer Thickness Surface Protection (µm) 18
Material Steel
Material Quality Class 8.8
Norm / Standard DIN 933
Screwing System External hexagon
Surface Protection BUP1000
Surface Treatment Untreated
Thread Direction Right-Handed Thread
Thread Type Ref. letter: TT Metric
Threading Fully threaded

Approvals & Declarations

Approvals & Declarations
UPC listing certificate No

Weights

Weights
Weight [g] (g) 40
Weight [kg] (kg) 0.04

Packaging information

Packaging information
Pack 1 Shape Bag
Pack 1 Qty 50
Pack 1 Height (mm) 25
Pack 1 Width (mm) 80
Pack 1 Length (mm) 80
Pack 1 Weight (g) 2010
Pack 2 Shape No Pack Type Available

Downloads & certificates

K4519 Walraven Hexagon Head Bolt (BUP1000) PDF | EN | Product info sheet Download
