Walraven Synthetic Floor Clamp single 14-20mm
for floor pipe
Features
- to fix pipe-in-pipe pipes before casting top floor layer
- material: PA (polyamide)
Specifications
Identification
| Product Number | 3911020 |
|---|
Product Dimensions
| Drill Hole Diameter (mm) Ref. letter: d0 | 6 |
|---|---|
| Height (mm) Ref. letter: h | 30 |
| Outside Pipe Diameter (mm) Ref. letter: D | 14 - 20 |
| Total Depth (mm) Ref. letter: DtT | 10 |
| Total Height (mm) Ref. letter: H | 48 |
| Total Width (mm) Ref. letter: W | 34 |
Technical characteristics
| Colour | Grey |
|---|---|
| Material | Plastic |
| Material Quality | PA Nylon 6 (PolyAmide Nylon 6) |
| Maximum Number Of Tubes | 1 |
| Surface Protection | Pre-galvanized |
| Surface Treatment | Untreated |
| Type Of Fastening | Moulded-on push fit plug |
Weights
| Weight [g] (g) | 3 |
|---|---|
| Weight [kg] (kg) | 0 |
Packaging information
| Pack 1 Shape | Cardboard Box |
|---|---|
| Pack 1 Qty | 500 |
| Pack 1 Height (mm) | 119 |
| Pack 1 Width (mm) | 264 |
| Pack 1 Length (mm) | 398 |
| Pack 1 Weight (g) | 1714 |
| Pack 2 Shape | Pallet ISO 0-1/1 |
| Pack 2 Qty | 31500 |
| Pack 2 Height (mm) | 977 |
| Pack 2 Width (mm) | 1200 |
| Pack 2 Length (mm) | 800 |
| Pack 2 Weight (g) | 128982 |
| Pack 3 Shape | No Pack Type Available |
