Walraven Foundation Clamp BUP 75mm
for sewer pipes
Features
- quick and easy installation
- round profiling prevents damage to the pipes
- for use with Foundation Bracket, Clamp Slide and Lock
- material: steel
- surface protection:
- product is part of the Walraven BIS UltraProtect® 1000 system
- suitable for in- and outdoor applications
- stands min. 1,000 hours salt spray test (max. 5% red rust) according to ISO 9227
Specifications
Identification
| Product Number | 4708024 |
|---|
Product Dimensions
| Fixing Hole (mm) Ref. letter: FH | 9 |
|---|---|
| Fixing Hole 2 (mm) Ref. letter: FH 2 | 9 |
| Outside Pipe Diameter (mm) Ref. letter: D | 75 |
| Total Depth (mm) Ref. letter: DtT | 140 |
| Total Height (mm) Ref. letter: H | 148.5 |
| Total Width (mm) Ref. letter: W | 22.5 |
Technical characteristics
| Material | Steel |
|---|---|
| Material Quality | St. 1.0242 |
| Surface Protection | BUP1000 |
| Surface Treatment | Untreated |
Weights
| Weight [g] (g) | 139 |
|---|---|
| Weight [kg] (kg) | 0.14 |
Packaging information
| Pack 1 Shape | Cardboard Box |
|---|---|
| Pack 1 Qty | 50 |
| Pack 1 Height (mm) | 184 |
| Pack 1 Width (mm) | 270 |
| Pack 1 Length (mm) | 404 |
| Pack 1 Weight (g) | 7336 |
| Pack 2 Shape | Pallet ISO 0-1/1 |
| Pack 2 Qty | 2250 |
| Pack 2 Height (mm) | 1064 |
| Pack 2 Width (mm) | 1200 |
| Pack 2 Length (mm) | 800 |
| Pack 2 Weight (g) | 351120 |
| Pack 3 Shape | No Pack Type Available |
