Walraven Pacifyre® NBR+ Bandage 10m 125x1.5

Fire protection bandage for insulated metal pipes

2136125010 Product line: Walraven Pacifyre®

Features

For sealing insulated, non-combustible pipes in R90 quality according to DIN 4102-11 or EI 90/120 according to EN 13501 in walls (solid walls or light partitions) and ceilings with fire protection requirements according to MBO or MLAR/LAR/RbALi
No tools and no drilling required
Just one product for many installations
Easy installation: place the bandage around the insulation, push it into the constrution, done!
Due to the small number of layers, it is ideal for areas that are difficult to access
Always with insulation
Weather-resistant material (against UV radiation and moisture | usage category X)
Little need for space
Zero distance to other insulation products possible (according to abP)
Tested by the Materials Testing Institute for Construction (MPA), Braunschweig in accordance with P-2401/142/19-MPA BS and externally monitored
ETA-20/0612

Identification
Product Number	2136125010

Product Dimensions
Length (mm) Ref. letter: l	10000
Intumescent Width (mm) Ref. letter: IW	125
Intumescent Layer Thickness (mm) Ref. letter: ILT	1.5
Total Height (mm) Ref. letter: H	1.5
Total Width (mm) Ref. letter: W	125
Total Depth (mm) Ref. letter: DtT	10000

Technical characteristics
Colour	Grey
Material	Intumescent

Approvals & Declarations
CE mark	Yes
European Technical Assessment (ETA)	Yes

Weights
Weight [g] (g)	2400
Weight [kg] (kg)	2.4
