Walraven IKS-2000® Text Card Holder Klik blue
for labeling of installations
Features
- individual pipe identification according to standard
- text card holders with click-effect for use in combination with individual printed textcards
- fixing of text card holders with stainless steel mounting band (0200300) or with velcro band (0200310)
- material: mounting cube made of PA (polyamide - nylon6); text card holder made of PP (polypropylene)
- temperature resistance from -15 °C to +80 °C
Specifications
Identification
| Product Number | 0209002 |
|---|
Product Dimensions
| Total Height (mm) Ref. letter: H | 58 |
|---|---|
| Total Width (mm) Ref. letter: W | 89.3 |
| Total Depth (mm) Ref. letter: DtT | 34 |
Technical characteristics
| Model | For use with suspension band |
|---|---|
| Colour | Blue |
| Material | Steel |
| Material Quality | St. 1.0330 |
| Surface Protection | Zinc Plated |
| Surface Treatment | Untreated |
Weights
| Weight [g] (g) | 37 |
|---|---|
| Weight [kg] (kg) | 0.04 |
Packaging information
| Pack 1 Shape | Bag |
|---|---|
| Pack 1 Qty | 10 |
| Pack 1 Height (mm) | 50 |
| Pack 1 Width (mm) | 200 |
| Pack 1 Length (mm) | 160 |
| Pack 1 Weight (g) | 375 |
| Pack 2 Shape | Cardboard Box |
| Pack 2 Qty | 250 |
| Pack 2 Height (mm) | 311 |
| Pack 2 Width (mm) | 398 |
| Pack 2 Length (mm) | 530 |
| Pack 2 Weight (g) | 9790 |
| Pack 3 Shape | Pallet ISO 0-1/1 |
| Pack 3 Qty | 6750 |
| Pack 3 Height (mm) | 1077 |
| Pack 3 Width (mm) | 1200 |
| Pack 3 Length (mm) | 800 |
| Pack 3 Weight (g) | 285330 |
| Pack 4 Shape | No Pack Type Available |
