Features & benefits
- for suspension of light components like cable trays, duct work, etc. onto beams without welding or drilling
- for fixing of rail to a steel beam
- material: steel
- zinc plated
| Part No. | For Rail Type | Thread Size | Thread Length | Total Height | Total Width | Total Length | Width | Material Thickness | Torque Moment For Installation | Maximum Allowed Load Faz | Pack 1 Type | Pack 1 QTY | Pack 2 Type | Pack 2 Qty | Product wish list |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Ref. letter | TS | TL | H | W | L | w | MT | T inst. | Fa,z | ||||||
| Unit desc. | (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | (Nm) | (N) | |||||||
| Part No.6070000 | For Rail Type 27x18 | Thread SizeTS M8 | Thread LengthTL (mm) 16 | Total HeightH (mm) 60 | Total WidthW (mm) 53 | Total LengthL (mm) 32 | Widthw (mm) 28 | Material ThicknessMT (mm) 2 | Torque Moment For InstallationT inst. (Nm) 15 | Maximum Allowed Load FazFa,z (N) 2350 | Pack 1 Type Cardboard Box | Pack 1 QTY 50 | Pack 2 Type No Pack Type Available | Pack 2 Qty - | Product wish list |
| Part No.6071000 | For Rail Type 30x15 | Thread SizeTS M8 | Thread LengthTL (mm) 16 | Total HeightH (mm) 66 | Total WidthW (mm) 70 | Total LengthL (mm) 36 | Widthw (mm) 31 | Material ThicknessMT (mm) 2.5 | Torque Moment For InstallationT inst. (Nm) 15 | Maximum Allowed Load FazFa,z (N) 1900 | Pack 1 Type Cardboard Box | Pack 1 QTY 50 | Pack 2 Type Pallet ISO 1 | Pack 2 Qty 4500 | Product wish list |
